Optical Cable Accessories



Attenuators

Bulkhead (Female to Female) Attenuator



Bulkhead Attenuator utilize a wavelength sensitive neutral density filters. Specify for 1310nm and 1550nm operation. Available in SC, ST, FC for 5dB, 10dB, 15dB, 20dB, 25dB, 30dB values.
Other values available on request.






Mode Conditioning Patch cord

Variable Attenuator (Clip-On Type)


Variable attenuator (Clip-On type) is a completely passive device which works by physical attenuation of a 3mm jacketed Singlemode cable. It can be attached at any point in a cable providing attenuation levels from 0 to >47dB at 1550nm, 0 to >21dB at 1310nm and low back reflection. Good for several uses.

In-Line Fixed Attenuator



The In-Line Fixed Attenuator is built to meet your low reflection attenuation requirements. Each cord is custom built upto 10 meters in length to accommodate your fiber length and connector type. The 5dB and 10dB version hold a +/- 0.5dB tolerance with the 15dB and 20dB holding a 1 dB tolerance. Please specify operating wavelength.


Plug Type (Male to Female) Attenuator



Plug type attenuator contains doped fiber suitable for dual wavelength operation. Available in FC, SC, ST, LC & MU for 5dB, 10dB, 15dB, 20dB   values. Other   values available on request.





Variable Attenuator (Connector Type)

This part combines the functions of a connector with a variable attenuator. High resolution of 0.1dB is attained by finely threaded self locking mechanism. Attenuation range is 0dB to 28dB.
